Product Description
|
Item
|
MCH Ceramic Heater Element
|
|
Application
|
Electronic industry, mechanical chemical industry
|
|
Material
|
Al2O3
|
|
Size
|
Customized, according to your drawing
|
|
Payment
|
TT, Western union, Credit Card
|
|
Packing& Shipping
|
1. Each item is wrapped with oppbag and protective air bubble 2. Then put into the box/Pack with strong Cartons for shipping
3. We use different packing methods according to different products, or we can use customized packing.
|
Introduction
The high-temperature co-fired ceramic heating element is directly printed with resistance paste on the Al2O3 alumina ceramic green body, and then co-fired at a high temperature of 1600 degrees Celsius. Then the electrodes and lead wires are processed to produce a new generation of low-temperature heating elements. It has simple structure, rapid heating, fast temperature compensation, high power density, high heating temperature, which can reach more than 500 degrees Celsius, high thermal efficiency, energy saving, uniform heating, no open flame, safe use, long life, reduced power attenuation, heating circuit and air isolated.
It is resistant to acid and alkali and meets environmental protection requirements. It is widely used in daily life, industrial agriculture, communication, medical treatment, and environmental protection. The current market ceramic heating elements include: sheet heating element, round rod heating element, disc heating element, round tube heating element, etc.d as innovative heater in machinery, medical.semiconductor,electronic & electrical industries,etc.
★Dense/lightweight/energy-saving High power density and good thermal efficiency
★Rapid heating Can customize temperature distribution Strong insulation, can directly come into contact with water, kerosene,and metals
★High reliability Dielectric strength and electrical insulation Due to its ability to prevent oxidation, the resistance material has a longer service life
|
Configuration
|
Plat
|
|
Dimension
|
70mm*15mm*1.3mm
|
|
Power(W)
|
≤500
|
|
Resistance Tolerance
|
±10%
|
|
Heating rate within 10 seconds
|
100 ℃-230℃
|
|
Heating rate within 30 seconds
|
500 ℃-700℃
|
|
Insulation resistance
|
R≥5X108Ω(500VDC)
|
|
Compressive strength per minute
|
1500VAC-4000VAC
|
|
Maximum applied voltage
|
230VAC/120VAC
|
|
Ceramic density
|
3.6/cm3
|
|
Bending strength
|
≥270MPa
|
|
Compressive strength
|
≥270MPa
|
|
Rated operating temperature
|
100 ℃-230℃
|
|
Maximum temperature
|
500 ℃-700℃
|
|
Thermal conductivity
|
25℃ 0.2W/cm
100℃ 0.14W/cm
200℃ 0.11W/cm
|
|
Heat capacity
|
25℃ 3.8caL/mol
100℃ 4.2caL/mol
200℃ 4.5caL/mol
|
|
Coefficient of thermal expansion
|
6.75*10-6/C
|
Company Profile
Jiangsu Zitai Co.Ltd
1.A professional Team!
Zitai have a full service include ceramic forming,molding design and development, precision machining and precision detection technology and we have a professional techincal teams and our engineer works in this line more 20years. We are good at listening and understanding your real needs and can provide exclusive personal customization!
2.A good listener!
Take the good faith as the book, strives for the survival by the quality, serves the quality to win the customer trust,maitain the spirit of innovation and development, thoughtful after-sales service enterprises as the goal.
3.Professional production equipment
We have dozens of professional equipment in line with EU production standards.Can be customized with your different production needs, different materials for production. Due to the high operation of the equipment, the production cycle can be greatly shortened.
4.Rigorous inspection process
We will be in the production of products after the professional technical personnel for product quality review and tolerance measurement. To ensure that the products sent to your hands are the best quality products.
FAQ
Q：Are you a manufacturer or trading company ?
A：We are professional manufacturer and supplier in China.we have a professional technical team in this line.
Q：What’s the MOQ?
A：There is no limit on quantity, the quantity is more,the price is better.
Q：Do you accept customized dimension?
A：Yes, we can produce ceramic parts per customer’s drawing.
Q：Can you supply a free sample?
A：We can supply a free sample to you within 3 days when we have an exsited size in our stock and the freight is collect.
We always send the sample before the mass production and keep the quality of the bulk goods is consistent with that of the sample.
Q：What about your after-sales service?
A：We have strict and professional QC team. We are always offering qualified products.
If the quality can not meet requirement, we will reproduce the qualified products or refund the payment.
Q：What is your payment term?
A：We mainly accept T/T, West Union, Credit card and L/C at sight.
Paypal will be available in the near future.
